300Mbps Multi-Mode Wireless N Router
- Fast Wi-Fi for Daily Life — MW301R provides fast and stable connections to meet all your network needs with speeds of up to 300 Mbps
- Broader Coverage — Equipped with high gain external antennas to deliver strong Wi-Fi signals to every corner of your home
- Multi-Mode — Four modes in one device to satisfy all application scenarios
- Easy installation — Intuitive webpage guides you through the setup process in minutes
- Active Parental Controls — Establish appropriate access policies to protect children with responsible, safe internet access
- Compatible with IPv6 (Internet Protocol version 6)
Fast Daily Wi-Fi
The MW301R provides fast, stable Wi-Fi for your connected devices. Wireless speeds of up to 300Mbps make it ideal for HD streaming, online gaming, and rapid file downloads.
Broader Coverage
Two external 5 dBi antennas powered with advanced antenna technology provide broader wireless coverage and signal intensity throughout large homes or offices, making weak connections a thing of the past.
4 Modes in 1
-
Internet MW301R Laptops Phones
Router Mode
Creates a wireless network for all your Wi-Fi devices
-
Internet Host Router Laptops Phones MW301R
Range Extender Mode
Extends your existing Wi-Fi
-
Internet Host Router Laptops Phones MW301R
Access Point Mode
Extends a wired network and makes it wireless
-
WISP MW301R Laptops Phones
WISP Mode
Wirelessly connects to the ISP network in areas without wired service
Easy Setup with MERCUSYS App
The MERCUSYS app provides the easiest way for you to set up in minutes and manage your WiFi through your iOS or Android devices.
Easily Manage Your Home Network
-
Parental Controls
Supervise children or staff by limiting access. Manage when and how connected devices can access the internet.
-
Guest Network
Allow guests to join your Wi-Fi network while protecting your privacy. Making sharing easy and maintaining security.
-
QoS
Priorities devices to get better
performance when needed. -
Wi-Fi Schedule
Customizes a schedule to automatically turn off your Wi-Fi.
-
IPTV Supported
Supports IGMP Proxy/Snooping, Bridge, and Tag VLAN to optimize IPTV streaming for a superior online experience.
-
LED Control
Sets a time to turn off the LED while you sleep.
-
Advanced Security
WPA/WPA2 encryption creates an active defense against security threats and intruders.
-
IPv6 Supported
Allows you to enjoy IPv6 services provided by your ISP and visit IPv6 websites.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
- Wireless
- Wireless Standards
- IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Frequency
- 2.4 - 2.4835GHz
- WiFi Speeds
11n: Up to 300Mbps (Dynamic)
11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic)
- Reception Sensitivity
270M: -70dBm@10% PER
130M: -74dBm@10% PER
108M: -77dBm@10% PER
54M: -76dBm@10% PER
11M: -90dBm@8% PER
6M: -92dBm@10% PER
1M: -97dBm@8% PER
- Transmission Power
- <20dBm
- Wireless Security
WPA-PSK / WPA2-PSK
- Wireless Functions
Enable/Disable Wireless Radio, WDS Bridging
- Hardware
- Dimensions
114 × 94 × 26 mm
- Interfaces
2× 10/100Mbps LAN ports
1× 10/100Mbps WAN port
- Button
Reset Button
- External Power Supply
- 5VDC/0.6A
- Antenna Type
- 2 x 5dBi fixed omni directional antennas
- Software
- WAN Type
- Dynamic IP/Static IP/PPPoE/L2TP/PPTP
- Management
Parental Control
Access control
Local management
Remote management
- DHCP
- Server
- Port Forwarding
- Virtual server, UPnP, DMZ
- Dynamic DNS
- DynDNS、NO-IP
- Firewall Security
- IP and MAC address binding
- Protocols
IPv4, IPv6
- Guest Network
- 2.4GHz guest network
- Others
- Certifications
- CE, ROHS
- Package Contents
300Mbps Multi-Mode Wireless N Router (MW301R)
Power adapter
Quick Installation Guide
Ethernet cable
- Environment
Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F)
Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F)
Operating humidity: 10% ~ 90%, non-condensing
Storage humidity: 5% ~ 90%, non-condensing
