MU6H [V1, V1.30] | AC650 High Gain Wireless Dual Band USB Adapter
AC650 High Gain Wireless Dual Band USB Adapter
- High-Speed Dual-Band Wi-Fi: 256-QAM support increases the 2.4 GHz data rate from 150 Mbps to 200 Mbps. Enjoy speeds of up to 200 Mbps on the 2.4 GHz band and 433 Mbps on the 5 GHz band, to take full advantage of your AC WiFi.
- High-Gain Antenna: A 5dBi high-gain antenna greatly enhances the reception and transmission strength of the USB adapter
- Plug and Play without CD: Plug and play on Windows 11/10 or easily download the driver from the MERCUSYS official website for other OS's.
- Adjustable Multi-Directional Antenna: Rotate and adjust the antenna in multiple directions to improve the user experience in various situations.
Fully Enhanced
Wi-Fi Performance
AC650 High Gain
Wireless Dual Band USB Adapter
AC650 Dual Band Wi-Fi
MU6H receives Wi-Fi signals on two separate bands. Supporting 256-QAM technology increases 2.4 GHz data rate from 150 Mbps to 200 Mbps for 33% faster performance. Choose the 2.4 GHz for surfing and social media, and 5 GHz for up to 433 Mbps for HD streaming and lag-free gaming.
-
5 GHz 433 Mbps
-
2.4 GHz 200 Mbps
Boost Wireless Range with High Gain Antenna
A 5 dBi high gain antenna reaches your router from farther with more precise directional range, sustaining faster and more stable wireless connections.
-
5 dBi
MU6H High Gain Antenna
-
2 dBi
Traditional Antenna
Plug and Play without CD
Plug and play on Windows 11/10 or easily download the driver from the MERCUSYS official website for other OS's. Just plug MU6H into the computer and follow the on-screen directions to set up your network in seconds.
No CD-ROM Required
Adjustable, Multi-Directional Antenna
Rotate and adjust the antenna in multi-direction to improve using experience and performance in different environments.
-
Operating System
Fully compatible with Windows
11/10/8.1/8/7/XP (32/64 bit). -
Advanced Security
WPA/WPA2 encryption standards keep your wireless connection safe from intruders.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, AP limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and AP location. ‡Use of 256-QAM requires your APs to also support 256-QAM. § Certain features of MU6H, such as plug and play, may be restricted on some operating systems and platforms. For Win 8.1/8/7/XP, you need to install the driver from https://www.mercusys.com/download/mu6h/
- Wireless
- Wireless Standards
IEEE 802.11b/g/n
IEEE 802.11a/n/ac- Frequency
2400 MHz -2483.5 MHz
5150 MHz -5250 MHz
5250 MHz -5350 MHz
5470 MHz -5725 MHz- WiFi Speeds
• 11ac: Up to 433Mbps (Dynamic)
• 11n: Up to 200Mbps (Dynamic)- Reception Sensitivity
• 433M: -62dBm@10% PER
• 200M: -65dBm@10% PER
• 54M: -75 dBm@10% PER
• 11M: -90 dBm@8% PER- Wireless Security
WEP, WPA/WPA2,
WPA-PSK/ WPA2-PS,
802.1X
- Hardware
- Dimensions
57.8 × 16.8 × 173.4 mm
(2.28 × 0.66 × 6.83 in)- Interfaces
USB 2.0
- Antenna Type
1× External High Gain
5dBi Antenna- LED
Status
- Others
- Package Contents
1. AC650 High Gain Wireless Dual Band USB Adapter ( MU6H )
2. Quick Installation Guide- System Requirements
Windows 11/10/8.1/8/7/XP
